SMART Sensor Specifications
| Physical Characteristics | SMART Gas Sensor: Dimension: 1.0″ Dia x 0.5″ H Weight: 0.22 oz (6.28 g) Sensor Module: Weight: 3.1 ounces (87.9 g) Dimension: 3.4″ L x 3.1″ W x 0.8″ H |
|---|---|
| Performance | Detection Range: 22 TICs & 8 CWAs (see Table) Sampling Rate: 1 Hz Detection Time (Avg): 23+ sec Alarm Time (Avg): 53+ sec Operating Temp: 0 to 50°C Humidity: 0 to 80% RH |
| SMART Sensor |
|
| Calibration | Auto-Calibration |
| Pump | 12 V DC Input and set at 100 ccm |
| Power | 24 V DC Input (9-36 V DC), 85 mA |
| Communications | USB |
